MP600PIII 250W 3 Mic & 2 AUX Mixing Amplifier
MP600PIII economy mixer amplifier is rated at 250W. It has 3 microphone inputs and 2 aux inputs, and Mic 1 is provided with priority and muting function. Bass and treble controls and master volume control are provided. Complete protection includes short circuit and thermal protection, current limiter and overloading.
This can be connected 70v amplifier mixer, which also can be called stereo mixing amplifier. This amplifier can be applied to different cases, such as supermarket, classroom, etc.
MP600PIII Features:
● 70V, 100V & 4-16 Ω, rated power 250W
● 3 microphone inputs, Mic 1 with priority and muting function
● 2 aux line input &1 line output for the additional mixer or amplifier link
● Individual volume control for each microphone and line input
● Bass and treble control.
| Model | MP600PIII Specification |
| Rated output | 250W |
| Speaker output | 70V, 100V & 4-16 Ω, |
| Input sensitivity | Mic2,3 : 600Ω, ≤3mV, unbalanced ;AUX1,2,MIC1 : 10kΩ, ≤300mV |
| Frequency response | 50Hz -16kHz (±3dB) |
| Distortion | < 1% at 1kHz , 1/3rated output voltage |
| The ratio of signal to noise | Mic1,2 and 3 : >75dB ;AUX1 and 2 : > 80dB |
| Protection | AC fuse; DC voltage; overload; short-circuit. |
| Power requirements | AC 220V-240V/50Hz-60Hz |
| Power consumption | 500W |
| Outer Packing Size (mm) | (L×W×H)520×430×195 |
| Unit Size (mm) | (L×W×H)420×338×88 |
| Gross weight | 10.3kg |
| Net weight | 8.5kg |
