Description

GS305P-5Port PoE Gigabit Ethernet Unmanaged Switch with 56 W Total PoE Budget

The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home/offices. They are easy to use, reliable, and rugged with metalenclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wirelessaccess points, etc. With these Plug-and-Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required. Available with 5 ports to 48 ports, these switches also support energy saving technologies to help you save power and money.

FEATURES :

• Choice of Fast Ethernet and Gigabit Ethernet connectivity
• Energy-efficient technology for power savings
• Auto-MDI/MDIX eliminates the need for crossover cables
• Non-blocking switching architecture for maximum throughput at wire speed
• Auto-negotiation for automatic connection at the highest common speed between switch and an end device
• Power-over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless access points, and other PD-powered devices
• Fanless design for silent operation
• Desktop, wall-mountable or rack-mountable (GS324, GS348)

Sturdy Metal Case

Get the NETGEAR quality and reliability for your entry-level switch with ease-of-use and placement. The sturdy metal case is built for reliability and quality installation.

Plug-and-Play Gigabit Connectivity

No need for an IT expert or a complicated user manual, just plug-and-play! Automatic connectivity to your router or modem of 4 additional wired connections at Gigabit speeds.

4-Port PoE with 55.5 W Budget

Connect multiple power demanding devices to your network with a single wire for power AND connectivity. Ideal for small installations of 4 PoE devices.

GS305P Specification :

Model

Brand

NETGEAR

Model

GS305P-100NAS

Format & Standards

Format

Desktop

Standards

802.3ab 1000BASE-T Gigabit Ethernet
802.3u 100BASE-TX Fast Ethernet
802.3i 10BASE-T Ethernet
802.3x Flow Control
802.1p Priority QoS (all models)
802.1p Priority QoS and Honors
802.3 CSMA / CD
802.3az Energy Efficient Ethernet

Network Management Type

Unmanaged

Ports & Interface

Primary Ports

5 x RJ45

Primary Port Speed

10/100/1000Mbps

Data Transmission

MAC Address Table

2K

Jumbo Frames

9720 bytes

Details

Buffer Memory

128KB

Protocols

TCP/IP

PoE

Yes

LEDs

Power, Link / Activity (Left)
Ports 1-4: PoE Power (Right)

Power

PoE Max Power Per Port: up to 15.4W
Total PoE Power Budget: up to 55.5W
DC Input: 48V / 1.25A
Power Consumption (Max and Standby): 60.0W / 0.96W

Dimensions & Weight

Dimensions

1.14″ x 6.22″ x 3.98″

Weight

0.90 lb.

Environmental

Temperature

Operating Temperature: 0 ~ 40 degree Celsius
Storage Temperature: -20 ~ 70 degree Celsius

Humidity

Operating Humidity: 90% maximum relative humidity, non-condensing
Storage Humidity: 5% to 95% relative humidity

Packaging

Package Contents

5-Port PoE Gigabit Ethernet Unmanaged Switch with 4-port PoE (GS305P)
Power adapter (48V DC, 1.25A power output); plug is localized to country of sale
Wall mount kit
Quick installation guide
