R&M CAT6 Cable

MPN: R795138YL
Model: CAT6 U/UTP FRPVC
Outer Jacket: Flame retardant-PVC; Conductor: Bare Solid Copper
Transmission frequency 250Mhz
4pair with cross separator; 3P and UL certified
Cable Length: 305 Meter

Compare
Categories: ,

Description

Specification

Connection Class
Standard ISO/IEC 11801 2nd ed.; EN 50173-1; ANSI/TIA-568-C.2 IEC 61156-5 2nd ed.; IEC 61156-7; EN 50288-6-1
Physical Specs
Color Yellow
Blue
Grey
Cable Details
Conductor Bare solid copper
Insulation HDPE, overall Ø 0.92±0.02 mm
Twisting 2 wires to the pair
Cable Lay-Up 4 pairs to the core with cross separator
Pair Screen Non
Overall Screen Non
Sheath PVC, gray RAL 7035, Sheath Thickness: 0.50mm nominal
Cable Information
Application Primary (Campus), Secondary (Riser), Tertiary (Horizontal) IEEE 802.3an: 10Base-T; 100Base-TX; 1000Base-T IEEE 802.5 16 MB; ISDN; TPDDI; ATM
Standards ISO/IEC 11801 2nd ed.; EN 50173-1; ANSI/TIA-568-C.2 IEC 61156-5 2nd ed.; IEC 61156-7; EN 50288-6-1
Fire Rating Flame retardant- PVC
Technical Detail
Cable Designation U/UTP Cat.6 250MHz
Packaging Drum 305 m
Outer Diameter 5.8±0.3mm
Weight 13.0kg nominal
Pulling Pressure 11Kg nominal
Segregation Class B
Tensile Strength > 16.5N/mm²
Bending Radius ≥ 25 mm during operation (without load)
≥ 50 mm during installation (with load)
Temperature ange During operation: -20°C…+ 60°C During installation: 0°C…+ 50°C
